Transaction Flow

Transaction List

The Reseller needs to develop the different transactions in order to get all the information required for creating a reservation that can be successfully sent to the Supplier via the Redeam Booking API.

Please note that the order in which the calls are made is very important. IDs received in the responses are used for the next request which would fail without these IDs.

Suppliers - mandatory
1. Get one supplier: GET /suppliers/{supplier_id}
2. Get multiple suppliers: GET /suppliers
Products - mandatory
1. Get one product: GET /suppliers/{supplierid}/products/{product id}
2. Get multiple products: GET /suppliers/{supplier_id}/products
Rates - mandatory
1. Get one rate: GET /suppliers/{supplierid}/products/{product id}/rates/{rate_id}
2. Get multiple rates: GET /suppliers/{supplier_id}/products/{product_id}/rates
Price Schedule - mandatory
1. GET/suppliers/{supplier_id}/products/{product_id}/pricing/schedule
Availability - mandatory
1. Retrieve a single availability: GET /suppliers/{supplierid}/products/{product id}/availability
2. Retrieve a list of availabilities: GET /suppliers/{supplier_id}/products/{product_id}/availabilities
Create Hold - mandatory
1. POST/holds
Create booking - mandatory
1. POST /bookings
Cancel booking - optional
1. PUT /bookings/cancel/{booking_id}
Retrieve hold - optional
1. GET /holds/{hold_id}
Release hold - optional
1. DELETE /holds/{hold_id}
Retrieve booking - optional
1. GET /bookings/{booking_id}

Transaction Diagram

This diagram shows the transaction dialog between you and Redeam. The numbers link the API call names and their link to the API spec to the order in which the call is made.

Transaction Flow Example

This example demonstrates the steps required for a booking using the Redeam Booking API referred to the numbers linking the calls to the diagram above:

1 Get Supplier

Request

JSON


curl --request GET \ --url 'https://booking.redeam.io/v1.2/suppliers?partner_id={partner_id}&code={code}' \ --header 'X-Request-ID: {X-Request-ID}' \ --header 'X-API-Key: {X-API-Key}' \ --header 'X-API-Secret: {X-API-Secret}'
Copy

Response

JSON


{    "meta": {        "data": {},        "reqId": "PostmanBookingAPI_9323aaa4-9cca-40fc-bb6d-da0be3c3e8e0"    },    "suppliers": [        {            "businessType": [],            "code": "WWW",            "contacts": [],            "ext": {},            "id": "1ab0c295-1d16-4b5e-8719-9e7eeb13b3c6",            "mainLocation": {                "name": "Wisconsin",                "notes": "",                "website": ""            },            "name": "Wisconsin Widget World",            "octoID": "1ab0c295-1d16-4b5e-8719-9e7eeb13b3c6",            "version": 2        },        {            "businessType": [],            "code": "9bd156aa-6a83-4f28-8667-bf6f9ec089fb2",            "contacts": [                {                    "email": "members.ny@fotografiska.com",                    "name": "",                    "phone": "",                    "title": ""                }            ],            "ext": {},            "id": "9bd156aa-6a83-4f28-8667-bf6f9ec089fb",            "name": "Fotografiska New York",            "octoID": "2",            "version": 321        },        {            "businessType": [],            "code": "STA",            "contacts": [],            "ext": {},            "hours": [                {                    "dates": [],                    "daysOfWeek": [],                    "times": [                        {                            "close": "17:00",                            "open": "08:00"                        }                    ],                    "timezone": "America/Chicago",                    "valid": {                        "from": "2018-10-19T23:37:31Z",                        "until": "2030-10-19T23:37:31Z"                    }                }            ],            "id": "fc49b925-6942-4df8-954b-ed7df10adf7e",            "mainLocation": {                "name": "Wisconsin",                "notes": "",                "website": ""            },            "name": "Sample Tours & Attractions",            "version": 3        }    ]}
Copy

2 Get Product

Request

JSON

curl --request GET \ --url 'https://booking.redeam.io/v1.2/suppliers/{supplier_id}/products?limit={limit}&offset={offset}&partner_id={partner_id}&code={code}' \ --header 'X-Request-ID: {X-Request-ID}' \ --header 'X-API-Key: {X-API-Key}' \ --header 'X-API-Secret: {X-API-Secret}'
Copy

Response

JSON


{
    "meta": {...},
    "products": [...]
}
Copy

3 Get Rate

Request

JSON

curl --request GET \ --url 'https://booking.redeam.io/v1.2/suppliers/{supplier_id}/products/{product_id}/rates?valid_during_end={valid_during_end}&valid_during_start={valid_during_start}&valid_from={valid_from}&valid_until={valid_until}&limit={limit}&offset={offset}&option_id={option_id}&partner_id={partner_id}&code={code}' \ --header 'X-Request-ID: {X-Request-ID}' \ --header 'X-API-Key: {X-API-Key}' \ --header 'X-API-Secret: {X-API-Secret}'
Copy

Response

JSON


{
    "meta": {...},
    "rates": [...]
}
Copy

4 Get Price Schedule

Request

JSON

curl --request GET \ --url 'https://booking.redeam.io/v1.2/suppliers/{supplier_id}/products/{product_id}/pricing/schedule?start_date={start_date}&end_date={end_date}&rate_id={rate_id}' \ --header 'X-API-Key: {X-API-Key}' \ --header 'X-API-Secret: {X-API-Secret}'
Copy

Response

JSON


{
    "0666f27f-2f16-4eba-91b7-28f08ce095d2": {...},
    "61d2ae81-b0e7-4570-bb26-4b634cbf84dd": {...},
    "e696402f-7dbf-4ae8-9881-8577665cf9af": {...}
}
Copy

5 Get Availability

Request

JSON

curl --request GET \ --url 'https://booking.redeam.io/v1.2/suppliers/{supplier_id}/products/{product_id}/availabilities?end={end}&start={start}&rate_id={rate_id}' \ --header 'X-Request-ID: {X-Request-ID}' \ --header 'X-API-Key: {X-API-Key}' \ --header 'X-API-Secret: {X-API-Secret}'
Copy

Response

JSON


{
    "availabilities": {...},
    "meta": {...}
}
Copy

6 Create Hold

Request

JSON


{  "hold": {    "ext": {      backend":"standard-adapter-mock-res"    },    "id": "f7393cf6-097d-443a-919a-ae3ca518e040",    "items": [      {        "at": "2023-01-22T16:00:00.000Z",        "availabilityId": "7894e608-d3e0-4e4a-9f3e-fef07c1ebae4",        "ext": {          backend":"standard-adapter-mock-res"        },        "id": "7b9cb23b-cba2-430f-b513-212a3be90c23"        "priceId": "cc7eea8c-6896-4ff3-82ff-a4399aea9264",        "productId":"02f0c6cb-77ae-4fcc-8f4d-99bc0c3bee18",        "quantity": 1,        "rateId": "0666f27f-2f16-4eba-91b7-28f08ce095d2",        "supplierId": "fc49b925-6942-4df8-954b-ed7df10adf7e",        "travelerType": "ADULT"      }    ],    "partnerId": "p0be"  },  "meta": {    "reqId": "5fd78809-4700-46d7-8386-3b8738117f4d"  }}
Copy

Response

JSON


{    "hold": {        "expires": "2023-01-18T14:03:28Z",        "ext": {            "backend": "standard-adapter-mock-res"        },        "id": "f7393cf6-097d-443a-919a-ae3ca518e040",        "items": [            {                "at": "2023-01-22T16:00:00.000Z",                "availabilityId": "7894e608-d3e0-4e4a-9f3e-fef07c1ebae4",                "ext": {                    "backend": "standard-adapter-mock-res"                },                "id": "7b9cb23b-cba2-430f-b513-212a3be90c23",                "priceId": "cc7eea8c-6896-4ff3-82ff-a4399aea9264",                "productId": "02f0c6cb-77ae-4fcc-8f4d-99bc0c3bee18",                "quantity": 1,                "rateId": "0666f27f-2f16-4eba-91b7-28f08ce095d2",                "supplierId": "fc49b925-6942-4df8-954b-ed7df10adf7e",                "travelerType": "ADULT"            }        ],        "status": "PENDING",        "timeline": [            {                "timestamp": "2023-01-17T14:03:28Z",                "typeOf": "PENDING"            },            {                "timestamp": "2023-01-17T14:03:28Z",                "typeOf": "OPEN"            }        ]    },    "meta": {        "data": {},        "reqId": "PostmanBookingAPI_c7bc5edf-56f1-48c9-803c-fb91e23a6639"    }}
Copy

7 Create Booking

Request

JSON


{    "booking": {      "barcode": {        "format": "UNKNOWN",        "value": "test"      },      "customer": {        "email": "daniel@g2rail.com"",        "firstName": "Daniel",        "lastName": "Teng"        "phone":""      },      "holdId": "f7393cf6-097d-443a-919a-ae3ca518e040",      "items": [          {             "availabilityId": "FHA[35578179]_S[2022-08-28T03:00:00-10:00]",             "productId": "{{product_id}}",             "priceId": "cc7eea8c-6896-4ff3-82ff-a4399aea9264",             "quantity": 1,             "rateId": "0666f27f-2f16-4eba-91b7-28f08ce095d2",             "startTime": "2023-01-22T16:00:00.000Z",             "supplierId": "fc49b925-6942-4df8-954b-ed7df10adf7e",             "traveler": {                 "age": 0,                 "country": "",                 "email": "daniel@g2rail.com",                 "firstName": "Daniel",                 "gender": "",                 "isLead": true,                 "lang": "",                 "lastName": "Teng",                 "type": "ADULT"             }         }      ],      "partnerId": "p0pg9"   }}
Copy

Response

JSON


{
    "booking": {...},
    "meta": {...}
}
Copy

8 Cancel Booking

Request

JSON


curl --request PUT \ --url 'https://booking.redeam.io/v1.2/bookings/cancel/{booking_id}' \ --header 'X-Request-ID: {X-Request-ID}' \ --header 'X-API-Key: {X-API-Key}' \ --header 'X-API-Secret: {X-API-Secret}'
Copy

Response

No response body, only 200 or other errors
